Power Distribution Boxes

To guarantee reliable performance, our distribution boxes are equipped with excellent brass terminals.   These terminals offer superior electrical conductivity, ensuring efficient power transmission and minimizing the risk of overheating or power loss.   With our distribution boxes, you can trust that your electrical connections are secure and well-maintained.

Power Distribution Boxes SHOW Series PRODUCT PROPERTIES

Colour: RAL 7035

Type of cover: Cover

Number of modules: 4way-12way

Number of rows: 1

Product accessories: Mounting fittings

IP protection level: IP65

Impact protection class：IK09

Flame retardant: 650℃ （30s）

Power Distribution Boxes SHOW Series ENVIRONMENTAL CONDITION

Application area: Indoor/Outdoor installation

Maximum ambient temperature 24 h: 35 °C

Ambient temperature: -5 °C up to +40 °C

Relative humidity: ≤ 50 % at 40 °C, ≤ 100 % at 25 °C

Power Distribution Boxes SHOW Series PERFORMANCE

Rated voltage: Un = 400 V

Rated insulation voltage：Ui:690V

Protection class:II

Rated current (of the terminal):In = 75 A

N separable:No

conforming to the standards:EN 60670-1, DIN EN 60670-24

Power Distribution Boxes SHOW Series MATERIAL CHARACTERISTICS

Material:ABS Shell / PC Door

According to IEC 60695-2-11 glow wire test temperature:650 °C

UL 94 Class:V-2

Temperature resistance:-25 °C up to +80 °C

Halogen-free:Yes

Silicone-free:Yes

Power Distribution Boxes SHOW Series  APPLICATION SCENARIO

Metallurgy, steel, nuclear power plant, power plant, chemical industry, tunnel engineering, subway, charging pile, photovoltaic
